Page 15 - Lahore Smart City

Integrated Transport System to Enhance Connectivity

400ft Wide
Main Boulevard (18-Lane)
Main gateway to LSC from Motorway

integrated Metro bus
system
Bus rapid tranit system
serving along two major
SMART Public transport hubs
transport corridors

MOBILITY Integrated commercial nodes
with multimodel transport
Interchange
INTEGRATED

TRANSPORT SYSTEM

FOR BETTER

CONNECTIVITY LEGEND

Main Boulevard (BRT-1)
Secondary Arterial (BRT-2)
Route 1 - LSC-Lahore BRT Line
Route 2 - LSC Bus Line
Metro Station
Waterbodies

13
0 500 1000 2000
Meters N
